Brief instruction

This dual filing machine with high accuracy is desiqned in terms of the National GMP Standard, Thekaging powdery & grainy product, for instance. mikpowder, rice powder, monosodium glutamate, solid beverage, dextrose, etc.

Engineered for high-efficiency and precision-focused powder packaging, the DJ-2B3 Automatic Double Auger Powder Can Filling Machine integrates advanced design elements to meet the demands of large-scale production across food, pharmaceutical, and chemical industries. Its eight key features work in synergy to balance speed, accuracy, hygiene, and ease of use-all while adhering strictly to the original specifications.

Scope of Applicable Products & Materials

This Automatic Double Auger Powder Can Filling Machine is suitable for a variety of powders, such as milk powder, wheat flour, rice flour, protein powder, seasoning powder, chemical powder, coffee powder, soybean powder, etc.

Technological Parameters

Model	DJ-2B3
Metering Mode	Double Auger filling, weighing feedback proportion tracked
Package Weight	10-5000g (by changing the auger attachment)
Package Accuracy	≤±1.5g(according to material )
Packing Speed	20-55times/min
Power Supply	380V/220V 50Hz/60Hz
Hopper Volume	50L+25L
Total Power	3.5kW
Total Weight	700kg
Overall Dimensions	240012002300mm
Interface	PLC control system, 5.7 inch touch screen
Container Size	Diameter 50-180mm; Height 50-350mm

Products Selling Points

Double Weight Feedback System, 50L+25L SUS 304 side opening hoppers

Stiring device keeps the powder falling down, don't stick on wall. Simple structure,smooth and no corner lining,easy to clean and operate.

Fully welded and polished screw,change for different filling weight

Siemens PLC, schneider electric parts, work stably and memory 10 recipes for different powder and filling weight

Touch screen, displays two lauguages on screen

Jacob glass cover, prevent the dust diffuse in room ,and keep room clean and no pollution. Outlet covers of hopper assure the dust small. If you need, the dust collector is allowed

Dust Remove Device, Factory Clean

With Cover Outlet, Assure Low Dust

Feature

1. Versatile Design & Simple Maintenance: Adapt to Diverse Needs

Flexibility is a standout trait of the DJ-2B3. By swapping out augers and small accessories, the machine seamlessly handles different powder types (from fine food powders to industrial chemical blends) and container sizes-no major overhauls required. This adaptability eliminates the need for multiple specialized machines, cutting equipment costs for businesses with varied product lines. Additionally, its logical mechanical structure makes maintenance straightforward: critical parts are easy to access, and replacements can be done quickly by on-site teams. This keeps the DJ-2B3 in top working order with minimal downtime.

2. Dual Auger System: Precision Powered by Teco Servo Motors

The DJ-2B3's performance hinges on its dual auger filling system, built for both accuracy and speed. Unlike single-auger models that struggle with uneven flow, the dual augers distribute powder consistently, reducing bottlenecks. Teco servo motors drive these augers, delivering controlled, stable motion that ensures each fill hits a precision mark of ≤±1.5g (depending on material properties). The dual setup also boosts filling speeds significantly-slashing per-unit processing time and lifting overall productivity for busy lines.

3. Two-Step Weight Checking: Eliminate Filling Errors

To guarantee every container meets weight standards, the DJ-2B3 includes a two-step weight verification system. After the initial fill, the machine runs a secondary check on each can or jar. If a unit is underfilled or overfilled, it's automatically rejected-keeping faulty products out of downstream processes (like sealing or labeling). This double layer of quality control cuts waste and upholds strict standards, which is critical for regulated industries like pharmaceuticals.

4. High-Speed Filling: 20–55 Cans Per Minute for Large-Scale Runs

Built for high-volume operations, the DJ-2B3 hits 20 to 55 cans per minute-perfect for facilities needing to meet tight production targets. What sets it apart? It doesn't trade speed for accuracy. Even at maximum throughput, the machine maintains consistent fills, avoiding the overfills/underfills that lead to wasted material or quality failures. This balance makes it a reliable workhorse for lines running at full capacity.

5. Dual Hoppers: Keep Production Flowing & Easy to Clean

The DJ-2B3 comes with two side-opening stainless steel hoppers (50L and 25L) that solve two big issues: downtime from refills and tough cleaning. The dual setup ensures continuous powder feed to the augers-while one hopper is refilled or cleaned, the other keeps running, keeping production gaps to a minimum. The side-opening design lets operators reach every corner of the hoppers, making residue removal and sanitization quick. Stainless steel construction also meets hygiene rules for food/pharmaceutical use, preventing contamination.

6. Customizable Touch Screen: Intuitive Control via Siemens PLC

Operating the DJ-2B3 is simple, thanks to its Siemens PLC control system and 5.7-inch touch screen. Siemens PLCs are known for reliability, so the machine runs steadily even during long shifts. The touch screen lets operators tweak settings (like target weight or auger speed), monitor filling in real time, and pull up diagnostics-all with easy taps. It also supports multiple languages (including Chinese and English), making it accessible to diverse teams. This user-friendly design cuts human error and shortens training for new staff.

7. Dust Control & Hygiene: Safe, Clean Operation

Hygiene and safety are baked into the DJ-2B3's design. A built-in vacuum cleaner catches dust from filling, stopping fine particles from spreading into the air, settling on equipment, or being inhaled by workers. This keeps the workspace clean and prevents cross-contamination from airborne dust. The machine also includes a can support system that stabilizes containers during filling-reducing spills and dust at the filling opening. Together, these features meet the strict cleanliness rules of food, pharmaceutical, and chemical industries.

8. Stable Power & Reliable Performance: Consistent Runs Every Time

The DJ-2B3 delivers steady performance with its flexible power system. It works with 380V or 220V supplies, adapting to regional electrical standards-ideal for global facilities or those relocating equipment. With a total power of 3.5kW, it balances efficiency and energy use, avoiding waste while handling high-volume tasks. Its tough build and quality electrical components ensure durability, even during nonstop operation. For lines running 24/7, this reliability means fewer breakdowns and less unplanned downtime.
