Brief Introduction
This Machine is an economical pracical powder automalic fling machine, which can complete automalic botle positioning, fling and metering.l consistsof a fling head, an independent motorized chain conveyor and a pneumatic positioning system. Suitable for fluidic low.luidity matenials, such as mikpowder, veterinary drugs, condiments, powdered additives, glucose, solid beverages talcum powder, peslicides, etc.
Technological Parameters
|
Model |
DJ-2B1 |
|
Metering Mode |
Auger filling |
|
Package Weight |
50-5000g (by changing the auger attachment) |
|
Package Accuracy |
≤±0.3-1%(according to the packaging weight and product size) |
|
Packing Speed |
10-20times/min |
|
Power Supply |
380V/220V 50Hz/60Hz |
|
Hopper Volume |
50L |
|
Total Power |
2kW |
|
Total Weight |
400kg |
|
Overall Dimensions |
2400*900*2150mm |
|
Interface |
PLC control system, 5.7 inch touch screen |
|
Container Size |
Diameter 20-100mm; Height 50-200mm |
Main Feature
All 304 Stainless steel side open hopper, more safe and healthier, easy to open and clean.
Servo motor drives screw working. PLC& Touch Screen make it easy to be operated.
Weight feedback and proportion track get rid of the shortage of variable packaged weight for various proportion of different material.
Support save 10 sets parameters of different filling weight for diferent materials.
Replacing the auger parts, It is suitable for super thin powder and granule.
