Brief Introduction

This semi-automatic filling and packaging machine was built right to meet the National GMP Standard-so you can trust it's up to industry rules for safety and hygiene.

First off, the hopper's transparent, so you can easily see what's going on inside. It also has a dust collection feature, which keeps things clean and tidy while it's running. And if you need to adjust the height of the working table? No problem-you can tweak it to fit what's most comfortable for you.

Another handy thing: it can save more than 10 different recipes. That means if you use specific settings for certain products, you don't have to reset everything each time-just pull up the saved recipe, and you're good to go.

As for what it can package? It's perfect for powdery stuff-think milk powder, feed, rice powder, icing sugar, coffee, monosodium glutamate (MSG), solid drinks, dextrose, and even solid medicines. Basically, all kinds of powdered products you might need to pack.

Technological Parameters

Model	DJ-1B3
Metering Mode	Auger filling, weighing feedback proportion tracked
Package Weight	50-5000g (by changing the auger attachment)
Package Accuracy	≤±0.3-1%(according to the packaging weight and product size)
Packaging Speed	15-60bags/min(according to the packaging weight and product size)
Power Supply	380V/220V 50-60Hz
Hopper Volume	50L
Total Power	1.8kW
Overall Dimensions	1200x700x2150mm
Operating Interface	PLC control system, 5.7 inch colorful touch screen

Products Selling Points

DJ-1B3 5kg Powder Auger Filling Machine 4

50L SUS 304 side opening hopper

DJ-1B3 5kg Powder Auger Filling Machine 5

Stiring device keeps the powder falling down, don't stick on wall. Simple structure,smooth and no corner lining,easy to clean and operate.

DJ-1B3 5kg Powder Auger Filling Machine 6

Fully welded and polished screw,change for different filling weight

DJ-1B3 5kg Powder Auger Filling Machine 7

Dust collector,collect the dust ,avoid to waste and keeps room clean.

DJ-1B3 5kg Powder Auger Filling Machine 8

Siemens touch screen,can display two lauguages on screen

DJ-1B3 5kg Powder Auger Filling Machine 9

Automatic Weight Feedback Scale

Products Description

DJ-1B3 Structure Diagram

Feature

All 304 Stainless steel side open hopper more safe and healthier, easy toopen and clean.
Servo motor drives screw working.
PLC& Touch Screen make it easy to be operated.

Weight feedback and proportion track get rid of the shortage of variablepackaged weight for various proportion of different material.

Support save 10 sets parameters of different filling weight for different materials

Replacing the auger parts, lt is suitable for super thin powder and granule.
