Automatic Vertical Shrink Wrapping Machine (20-30 Packs/Min)





Our automatic vertical shrink wrapping machine includes two high-performance models (HF-7050 and HT-500G), designed for efficient packaging of cosmetics, pharmaceuticals, food, and electronics-with PLC control and stable sealing effect.The fully automatic vertical up and down heat shrink packaging machine adopts a vertical sealing design, with good sealing stability, strong and beautiful sealing lines, and equipped with safety protection devices. The cutting blade position has a lifting function, and the sealing line can adjust the center position of the product. The output can reach 20-45 pieces per minute, and it can also be connected to unmanned production lines for use.









The HF-7050 automatic vertical shrink wrapping machine reaches 20-45 bags/min, equipped with Omron PLC and Schneider electrical parts-easy to operate, ideal for small-to-medium production lines.



Model HF-7050(Vertical Shrink Wrapping Main Machine)



Parameter	Details
Maximum sealing size	L700mm×W500mm
Suitable Product Size	L+H≤630mm W+H≤450 H≤180mm(for boxes/cosmetics)
Packaging speed	20～45bag/min
Power supply and total power	220V/50Hz 2.5kw
Maximum current	10A
Air source	6kg/cm2
Machine weight	660kg
Machine dimensions	(L)1900×(W)1400×(H)1600mm



Model HT-500G(Shrinkage Furnace Matching Accessory)



Parameter	Details
Furnace Cavity Size	L1500 × W500 × H350mm
Suitable Product Size	W400×H300mm(matched with HF-7050)
Conveying Speed	0-35m/min
Power supply and total power	380V/50Hz 14kw
Maximum current	32A
Machine weight	560kg
Machine dimensions	2000(L)×1070(W)×1230(H)







• Stable & Efficient Operation: PLC control system ensures consistent sealing and shrink effect, 20-45 bag/min speed meets small-to-medium production needs.
• Perfect Matching Design: HF-7050 main machine + HT-500G shrinkage furnace are pre-matched, no need for extra adjustment, plug-and-play.
• Wide Application: Suitable for boxes, cosmetics, small cans, and other irregular products-supports OEM customization for special product sizes.
• Reliable Quality & Certification: CE certified, thickened steel frame and high-quality heating tube extend service life, reduce maintenance cost.
• Easy to Operate: Touch screen control, simple parameter setting, no professional training required for operators.







Suitable for industries such as cosmetics, photo frames, pharmaceuticals, daily chemical products, hardware, printing, color boxes, food, electronics, greeting cards, etc.



Our automatic vertical shrink wrapping machine (HF-7050/HT-500G) is widely used in food packaging (snacks, beverages), cosmetic packaging (skincare boxes), and pharmaceutical packaging (medicine boxes)-meets industry hygiene standards.







• Cosmetics industry: Carton packaging for lipstick sets, skincare gift boxes
• Food industry: Small can packaging for nuts, snack boxes, beverage bottle bundles
• Daily chemical industry: Packaging for detergent small boxes, tissue box sets
• Pharmaceutical industry: Blister pack boxes, medical device small cartons







Our HT-500G automatic vertical shrink wrapping machine features 8 finned heating tubes and Panasonic inverter, with 0-35m/min speed-suitable for large-scale unmanned production lines.



No.	Name	Brand	Unit	Quantity
1	PLC	Omron	A	1
2	Temperature controller	Omron	A	2
3	Proximity switch	Omron	A	3
4	Travel switch	Omron	A	1
5	Travel switch	Omron	A	2
6	Switching power supply	Ming Wei	A	1
7	Travel switch cover	Omron	A	2
8	Travel switch	Omron	A	1
9	Travel switch cover	Omron	A	1
10	Solid state relay with small socket	Shiyan	A	2
11	Buzzer	Schneider/Schneider	A	1
12	Communication contactor	LS	A	2
13	Power switch	Oh my god	A	1
14	Indicator light	Peace	A	1
15	Insurance seat	Delixi/DEL IXI	A	2
16	Insurance management	Delixi/DEL IXI	A	2
17	Thermocouple	CHINKONG	A	2
18	Exhaust fan	SUNON	A	1
19	Exhaust fan stainless steel mesh	SUNON	A	1
20	Exhaust fan mesh cover	SUNON	A	2
21	Circuit breaker	Mitsubishi/MITSUBISHI	A	1
22	Proximity switch	Panasonic	A	4
23	Intermediate relay	Weidmuller	A	11
24	Intermediate relay seat	Weidmuller	A	11
25	Intermediate relay	Weidmuller	A	2
26	Intermediate relay seat	Weidmuller	A	2
27	The intermediate relay flashes yellow	Weidmuller	A	13
28	Select switch contacts with lock	Schneider/Schneider	A	1
29	Select switch	Schneider/Schneider	A	2
30	Emergency stop switch	Schneider	A	2
31	Heating tube	YIXING	A	1
32	Heating tube	YIXING	A	1
33	Safety switch	SCHMERSAL	Set up	1
34	Touch screen	Kunlun Tong State	A	1
35	Electromagnetic valve	Original Yadeke	A	1
36	Motor+reducer	Zhongda University	Set up	2
37	Motor+reducer		Set up	1
38	Motor+reducer		Set up	1
39	Photoelectric switch	Panasonic	Set up	3
40	Vertical motor	Dongli	Set up	1
41	Single phase brake motor	Dongli	Set up	1
42	Brake controller with seat		Set up	1
43	Magnetic switch	AIRTAC	A	1
44	Magnetic switch holder	AIRTAC	A	1
45	Variable frequency drive	Panasonic	Taiwan	2







No.	Configuration	Name	Product  Cards	Unit	Quantity
1	Standard	Motor	Tianyang	A	1
2	Standard	Horizontal motor	Dongli	A	1
3	Standard	Variable frequency drive	Panasonic	A	1
4	Standard	Variable frequency drive	Panasonic	A	1
5	Standard	Optoelectronics	Panasonic	Yes, that's right	1
6	Standard	Temperature controller	Omron/OMRON	A	1
7	Standard	Switching power supply	Ming Wei	A	1
8	Standard	U-shaped heat sink heating tube	Finned	Article	8
9	Standard	Select switch	Schneider	Set up	1
10	Standard	Emergency stop switch	Schneider	Set up	2
11	Standard	Flat head start button (green)	Schneider	Set up	2
12	Standard	Flat head stop button (red)	Schneider	Set up	2
13	Standard	N0 contact point	Schneider/Schneider	A	2
14	Standard	Intermediate relay	Weidmuller	A	2
15	Standard	Intermediate relay seat	Weidmuller	A	2
16	Standard	Spring plate	Weidmuller	A	2
17	Standard	Solid state relay	ANV	A	1
18	Standard	Solid state relay heat sink	ANV	A	1
19	Standard	Communication contactor	LS	A	1
20	Standard	Circuit breaker	Mitsubishi	A	1
21	Standard	Power switch	Oh my god	A	1
22	Standard	Exhaust fan	SUNON	A	1
23	Standard	Exhaust fan stainless steel mesh	SUNON	A	1
24	Standard	Exhaust fan mesh cover	SUNON	A	2
25	Standard	Power indicator light	Peace/HYP	A	1
26	Standard	Thermocouple	CHINKONG	Article	1
27	Standard	Insurance seat	DELIXI	A	3
28	Standard	Light bulb		A	1
29	Standard	Lamp head		A	1





Q: Can the machine be customized for special product sizes?

A: Yes, provide your product's L/W/H dimensions (max L+H≤630mm) for a tailored solution.



Q: Can it handle irregular-shaped cosmetic gift boxes or small food cans?

A: Sure, the adjustable clamping device fits irregular products, with a max suitable height of 180mm.



Q: Does it meet hygiene standards for cosmetic and food packaging?

A: Yes, detachable parts and smooth surfaces allow easy cleaning, complying with relevant industry standards.



Q: Is the machine suitable for small workshops with limited space?

A: Absolutely, the compact design (main machine: 1900×1400×1600mm) saves space, no need for large installation area.
